FOX Shock Mounting Hardware
The flanged bushing eyelet hardware assembly is made up of two beige colored flanged bushings that are pressed into the shock eyelet. A hollow pin is pushed through the flanged bushings and centered by black Delrin spacers on either side of the eyelet. Thin o-rings go between the spacers and flanged bushings to prevent contamination and premature bushing wear.
| PART NUMBER | 803-03-256 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 19.05mm |
| PART NUMBER | 803-03-257 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 20.83mm |
| PART NUMBER | 803-03-258 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 21.84mm |
| PART NUMBER | 803-03-259 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 22.2mm |
| PART NUMBER | 803-03-260 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 23.88mm |
| PART NUMBER | 803-03-261 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 24.64mm |
| PART NUMBER | 803-03-262 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.15mm |
| PART NUMBER | 803-03-263 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.4mm |
| PART NUMBER | 803-03-264 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.91mm |
| PART NUMBER | 803-03-265 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 27.94mm |
| PART NUMBER | 803-03-266 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 28.45mm |
| PART NUMBER | 803-03-267 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 29.97mm |
| PART NUMBER | 803-03-268 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 30.43mm |
| PART NUMBER | 803-03-269 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 31.75mm |
| PART NUMBER | 803-03-270 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 32.05mm |
| PART NUMBER | 803-03-271 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.83mm |
| PART NUMBER | 803-03-272 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 35.05mm |
| PART NUMBER | 803-03-273 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 38.61mm |
| PART NUMBER | 803-03-274 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 39.88mm |
| PART NUMBER | 803-03-275 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 41.15mm |
| PART NUMBER | 803-03-276 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 49.78mm |
| PART NUMBER | 803-03-277 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 19.05mm |
| PART NUMBER | 803-03-278 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 21.54mm |
| PART NUMBER | 803-03-279 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 21.84mm |
| PART NUMBER | 803-03-280 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 22.2mm |
| PART NUMBER | 803-03-281 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 22.86mm |
| PART NUMBER | 803-03-282 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 23.37mm |
| PART NUMBER | 803-03-283 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 23.88mm |
| PART NUMBER | 803-03-284 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 24.89mm |
| PART NUMBER | 803-03-285 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.15mm |
| PART NUMBER | 803-03-286 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.4mm |
| PART NUMBER | 803-03-287 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 26.92mm |
| PART NUMBER | 803-03-288 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 27.43mm |
| PART NUMBER | 803-03-289 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 27.94mm |
| PART NUMBER | 803-03-290 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 28.8mm |
| PART NUMBER | 803-03-291 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 29.97mm |
| PART NUMBER | 803-03-292 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 31.75mm |
| PART NUMBER | 803-03-293 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 32.39mm |
| PART NUMBER | 803-03-294 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.02mm |
| PART NUMBER | 803-03-295 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.83mm |
| PART NUMBER | 803-03-296 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.99mm |
| PART NUMBER | 803-03-297 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 35.05mm |
| PART NUMBER | 803-03-298 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 35.56mm |
| PART NUMBER | 803-03-299 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 37.59mm |
| PART NUMBER | 803-03-300 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 38.61mm |
| PART NUMBER | 803-03-301 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 39.88mm |
| PART NUMBER | 803-03-302 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 41.15mm |
| PART NUMBER | 803-03-303 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 41.55mm |
| PART NUMBER | 803-03-304 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 42.19mm |
| PART NUMBER | 803-03-305 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 43.69mm |
| PART NUMBER | 803-03-306 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 44.86mm |
| PART NUMBER | 803-03-307 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 45.72mm |
| PART NUMBER | 803-03-308 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 47.75mm |
| PART NUMBER | 803-03-309 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 49.78mm |
| PART NUMBER | 803-03-311 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 54mm |
| PART NUMBER | 803-03-312 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.91mm |
| PART NUMBER | 803-03-313 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 36mm |
| PART NUMBER | 803-03-314 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 39.88mm |
| PART NUMBER | 803-03-315 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 33.53mm |
| PART NUMBER | 803-03-316 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 29.92mm |
| PART NUMBER | 803-03-317 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 22.2mm |
| PART NUMBER | 803-03-318 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 59.94mm |
| PART NUMBER | 803-03-319 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 51.89mm |
| PART NUMBER | 803-03-320 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 38.1mm |
| PART NUMBER | 803-03-321 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 59.94mm |
| PART NUMBER | 803-03-322 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 20mm |
| PART NUMBER | 803-03-323 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 30mm |
| PART NUMBER | 803-03-324 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 25mm |
| PART NUMBER | 803-03-325 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 40mm |
| PART NUMBER | 803-03-326 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 20mm |
| PART NUMBER | 803-03-327 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 20mm |
| PART NUMBER | 803-03-328 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25mm |
| PART NUMBER | 803-03-329 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 40mm |
| PART NUMBER | 803-03-331 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.68mm |
| PART NUMBER | 803-03-332 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 45.72mm |
| PART NUMBER | 803-03-333 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 21.08mm |
| PART NUMBER | 803-03-334 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 44mm |
| PART NUMBER | 803-03-335 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 55mm |
| PART NUMBER | 803-03-336 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 39.88mm (offset spacers) |
| PART NUMBER | 803-03-337 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 49.78mm (offset spacers) |
| PART NUMBER | 803-03-338 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 49.78mm (offset spacers) |
| PART NUMBER | 803-03-340 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 35mm |
Shipping & returns policy
Apparel & Bicycle Product Flat Rate Shipping
We offer free standard shipping on orders of $99 and above. We offer standard flat rate shipping for $10 on orders below $99. Please note we do not ship outside of the USA. Please visit our Canadian, European or Australian FOX Shop for international shipment. Typically you will receive a tracking number within 2 business days following your order.
Motorcycle Product Flat Rate Shipping
We offer free standard shipping on orders of $99 and above. Please note we do not ship outside of the USA. Typically you will receive a tracking number within 2 business days following your order.
Exchanges
Due to the high demand of our products, the fastest way to ensure you can exchange an online order for the product you would like is to please go ahead and purchase that new product immediately from the website. Following that please fill out the returns form and following instructions from our Customer Service team, send the product back for a refund. Please note we do not refund shipping charges and all products must be returned with original packaging in unused condition.
Returns
Within 30 days of purchase online FOX will accept returns of all returned with original packaging in unused condition. To initiate the return please fill out the returns form below and await contact by email from our Customer Service Team. Please note shipping charges will not be refunded.
Orders placed between November 15, 2024 and December 31st, 2024 may be returned for refund by February 1st, 2025. Note all other terms of returns are required. Products must be in original packaging in unused condition.
| PART NUMBER | 803-03-256 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 19.05mm |
| PART NUMBER | 803-03-257 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 20.83mm |
| PART NUMBER | 803-03-258 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 21.84mm |
| PART NUMBER | 803-03-259 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 22.2mm |
| PART NUMBER | 803-03-260 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 23.88mm |
| PART NUMBER | 803-03-261 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 24.64mm |
| PART NUMBER | 803-03-262 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.15mm |
| PART NUMBER | 803-03-263 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.4mm |
| PART NUMBER | 803-03-264 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.91mm |
| PART NUMBER | 803-03-265 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 27.94mm |
| PART NUMBER | 803-03-266 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 28.45mm |
| PART NUMBER | 803-03-267 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 29.97mm |
| PART NUMBER | 803-03-268 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 30.43mm |
| PART NUMBER | 803-03-269 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 31.75mm |
| PART NUMBER | 803-03-270 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 32.05mm |
| PART NUMBER | 803-03-271 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.83mm |
| PART NUMBER | 803-03-272 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 35.05mm |
| PART NUMBER | 803-03-273 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 38.61mm |
| PART NUMBER | 803-03-274 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 39.88mm |
| PART NUMBER | 803-03-275 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 41.15mm |
| PART NUMBER | 803-03-276 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 49.78mm |
| PART NUMBER | 803-03-277 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 19.05mm |
| PART NUMBER | 803-03-278 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 21.54mm |
| PART NUMBER | 803-03-279 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 21.84mm |
| PART NUMBER | 803-03-280 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 22.2mm |
| PART NUMBER | 803-03-281 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 22.86mm |
| PART NUMBER | 803-03-282 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 23.37mm |
| PART NUMBER | 803-03-283 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 23.88mm |
| PART NUMBER | 803-03-284 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 24.89mm |
| PART NUMBER | 803-03-285 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.15mm |
| PART NUMBER | 803-03-286 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.4mm |
| PART NUMBER | 803-03-287 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 26.92mm |
| PART NUMBER | 803-03-288 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 27.43mm |
| PART NUMBER | 803-03-289 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 27.94mm |
| PART NUMBER | 803-03-290 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 28.8mm |
| PART NUMBER | 803-03-291 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 29.97mm |
| PART NUMBER | 803-03-292 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 31.75mm |
| PART NUMBER | 803-03-293 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 32.39mm |
| PART NUMBER | 803-03-294 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.02mm |
| PART NUMBER | 803-03-295 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.83mm |
| PART NUMBER | 803-03-296 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.99mm |
| PART NUMBER | 803-03-297 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 35.05mm |
| PART NUMBER | 803-03-298 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 35.56mm |
| PART NUMBER | 803-03-299 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 37.59mm |
| PART NUMBER | 803-03-300 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 38.61mm |
| PART NUMBER | 803-03-301 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 39.88mm |
| PART NUMBER | 803-03-302 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 41.15mm |
| PART NUMBER | 803-03-303 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 41.55mm |
| PART NUMBER | 803-03-304 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 42.19mm |
| PART NUMBER | 803-03-305 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 43.69mm |
| PART NUMBER | 803-03-306 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 44.86mm |
| PART NUMBER | 803-03-307 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 45.72mm |
| PART NUMBER | 803-03-308 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 47.75mm |
| PART NUMBER | 803-03-309 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 49.78mm |
| PART NUMBER | 803-03-311 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 54mm |
| PART NUMBER | 803-03-312 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25.91mm |
| PART NUMBER | 803-03-313 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 36mm |
| PART NUMBER | 803-03-314 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 39.88mm |
| PART NUMBER | 803-03-315 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 33.53mm |
| PART NUMBER | 803-03-316 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 29.92mm |
| PART NUMBER | 803-03-317 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 22.2mm |
| PART NUMBER | 803-03-318 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 59.94mm |
| PART NUMBER | 803-03-319 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 51.89mm |
| PART NUMBER | 803-03-320 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 38.1mm |
| PART NUMBER | 803-03-321 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 59.94mm |
| PART NUMBER | 803-03-322 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 20mm |
| PART NUMBER | 803-03-323 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 30mm |
| PART NUMBER | 803-03-324 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 25mm |
| PART NUMBER | 803-03-325 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 40mm |
| PART NUMBER | 803-03-326 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 20mm |
| PART NUMBER | 803-03-327 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 20mm |
| PART NUMBER | 803-03-328 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 25mm |
| PART NUMBER | 803-03-329 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 40mm |
| PART NUMBER | 803-03-331 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 33.68mm |
| PART NUMBER | 803-03-332 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 45.72mm |
| PART NUMBER | 803-03-333 |
| DIAMETER | 6mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 21.08mm |
| PART NUMBER | 803-03-334 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 44mm |
| PART NUMBER | 803-03-335 |
| DIAMETER | 8mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 55mm |
| PART NUMBER | 803-03-336 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 39.88mm (offset spacers) |
| PART NUMBER | 803-03-337 |
| DIAMETER | 8mm |
| MATERIAL | Aluminium |
| MOUNTING WIDTH | 49.78mm (offset spacers) |
| PART NUMBER | 803-03-338 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 49.78mm (offset spacers) |
| PART NUMBER | 803-03-340 |
| DIAMETER | 10mm |
| MATERIAL | Stainless Steel |
| MOUNTING WIDTH | 35mm |
Shipping & returns policy
Apparel & Bicycle Product Flat Rate Shipping
We offer free standard shipping on orders of $99 and above. We offer standard flat rate shipping for $10 on orders below $99. Please note we do not ship outside of the USA. Please visit our Canadian, European or Australian FOX Shop for international shipment. Typically you will receive a tracking number within 2 business days following your order.
Motorcycle Product Flat Rate Shipping
We offer free standard shipping on orders of $99 and above. Please note we do not ship outside of the USA. Typically you will receive a tracking number within 2 business days following your order.
Exchanges
Due to the high demand of our products, the fastest way to ensure you can exchange an online order for the product you would like is to please go ahead and purchase that new product immediately from the website. Following that please fill out the returns form and following instructions from our Customer Service team, send the product back for a refund. Please note we do not refund shipping charges and all products must be returned with original packaging in unused condition.
Returns
Within 30 days of purchase online FOX will accept returns of all returned with original packaging in unused condition. To initiate the return please fill out the returns form below and await contact by email from our Customer Service Team. Please note shipping charges will not be refunded.
Orders placed between November 15, 2024 and December 31st, 2024 may be returned for refund by February 1st, 2025. Note all other terms of returns are required. Products must be in original packaging in unused condition.
